BIXOLON SPP-L3000 - Using Quad Battery Charger (Optional)

Ver. 1.00
- 14 -
SPP-L3000
3-2-3 Using Quad Battery Charger (Optional)
3-2-3-1 Connecting the cables
1) Connect the power cord to the adaptor,
and Connect the adaptor to the power
connector of the quad battery charger.
2) Plug the power cord into a power Outlet.
Input power is 100 ~ 240VAC, 50/60Hz,
1.0A.
3) When the power is supplied, the yellow,
green and red LEDs are on for three
seconds and do the self-test.
Warning
Use only designated AC adaptor. (12VDC, 3A)
