BIXOLON SRP-350plusV User Manual

Network Connection Manual
Ver.1.00
- 31 -
7-2 Initializing On-Board Ethernet / WLAN Setting
After the printer has finished booting, open the printer cover and press and hold the
FEED Button for 5 seconds. This will cause the interface setting confirmation mode.
Then add the paper, close the cover, and check that the following message is printed.
Checking Interface Setting
0: Exit
1: LAN Information Print
2: LAN Factory Reset and Reboot Printer
3: WLAN Information Print
4: WLAN Factory Reset and Reboot Printer
5 or more: None
Select Modes by Feed button control
as below.
Step 1. Short-press as many times as
The mode number to choose.
Step 2. Long-press over 1 second.
*e.g. To choose Mode 2, press Feed
Button 3 times(short-short-long)
Cover Open Button
FEED
Button

BIXOLON SRP-350plusV Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 / 60 Hz
Maximum roll diameter	79.5 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Yes
Serial interface	-
Optional connectivity	Bluetooth, Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Internal memory	- MB
Autocutter durability	2 million cuts

Weight and Dimensions

Depth	200 mm
Width	145 mm
Height	146 mm
