BIXOLON SRP-350plusV User Manual

Network Connection Manual
Ver.1.00
- 7 -
4-1 Connecting Printer
1) USB cable
Connect USB cable to Printer, PC device.
Use the “Net Configuration Tool” to adjust the settings.
2) WLAN
Connect to the AP (Access Point) configured in Infrastructure mode in order to connect
to the LAN/wireless network
Infrastructure mode
In order to configure the network between the wireless host device and the printer,
set the printer to Soft AP Mode.
Soft AP mode
* Soft AP mode is only supported on IFJ-WD.
A P

BIXOLON SRP-350plusV Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 / 60 Hz
Maximum roll diameter	79.5 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Yes
Serial interface	-
Optional connectivity	Bluetooth, Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Internal memory	- MB
Autocutter durability	2 million cuts

Weight and Dimensions

Depth	200 mm
Width	145 mm
Height	146 mm
