BIXOLON SRP-350plusV User Manual

Network Connection Manual
Ver.1.00
- 4 -
1. Introduction
This Network manual provides information on the connection of network with the
Industrial Label printer.
2. Precaution
1) The printer has to be within 100m(Outdoor) from AP(Access point) to connect
WLAN. Although 35m is able to communicate in door, WLAN could be affected by
environment to be shorten.
2) The maximum separating distance may be shortened if transmission obstacles,
such as cement walls, are present.
3) If a device (such as a microwave oven, wireless LAN, etc.) that uses the same
frequency is present, transmission may be interrupted. Separate the printer and
Bluetooth-enabled device from such interrupting devices by a distance of at least 5m.

BIXOLON SRP-350plusV Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 / 60 Hz
Maximum roll diameter	79.5 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Yes
Serial interface	-
Optional connectivity	Bluetooth, Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Internal memory	- MB
Autocutter durability	2 million cuts

Weight and Dimensions

Depth	200 mm
Width	145 mm
Height	146 mm
