BIXOLON SRP-350plusV User Manual

Network Connection Manual
Ver.1.00
- 32 -
If the above message is printed, select Mode 2 / 4, and you will see the following WLAN
information.
- To select Mode 2, press the Feed button twice quickly / once long.
- To select Mode 4, press the Feed button four times quickly / once long.
LAN(WLAN) Factory Reset OK! Reboot Printer.
After the above message is printed, the printer will automatically reboot.
Factory Reset Values
LAN Network
Inactivity time
0
IP Assignment
Method
Automatic(DHCP)
Local Port
9100
WLAN
System
Printer Name
*Printer model
Printer Port Num
9100
User ID
admin
User Password
password
Enc / Auth
Encryption
None/Open
Network
Network Mode
Soft AP mode
SSID
PRINTER_{MAC address}
Inactivity time
10
IP Assignment
Method
Manual (DHCP server)
IP, Subnet,
Gateway
IP : 192.168.1.1
Subnet : 255.255.255.0
Gateway : 192.168.1.2

BIXOLON SRP-350plusV Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 / 60 Hz
Maximum roll diameter	79.5 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Yes
Serial interface	-
Optional connectivity	Bluetooth, Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Internal memory	- MB
Autocutter durability	2 million cuts

Weight and Dimensions

Depth	200 mm
Width	145 mm
Height	146 mm
