BIXOLON SRP-352plusIII User Manual

SRP-352plusIII
Rev. 1.01
- 43 -
6-2 “FontControl” Font
This Windows driver supports the special functions as shown in the following table.
Select the “FontControl” character first and use the characters in the table to use the
special functions. Take care as this function is not for printing general texts.
Character
Special Functions
5
Print HT (0 x 09)
6
Print LF (0 x 0A)
7
Print CR (0 x 0D)
a
Open Drawer 2 (50ms driver pulse width)
b
Open Drawer 2 (100ms driver pulse width)
c
Open Drawer 2 (150ms driver pulse width)
d
Open Drawer 2 (200ms driver pulse width)
e
Open Drawer 2 (250ms driver pulse width)
f
Open Drawer 2 without paper feeding (50ms driver pulse width)
g
Cut without paper feeding
i
Print double size color image stored in the address 00
j
Print double size color image stored in the address 01
k
Print double size color image stored in the address 02
l
Print double size color image stored in the address 03
m
Print double size color image stored in the address 04
p
Do not add HRI characters to barcode
q
Add HRI characters above the bard code with FontA
r
Add HRI characters below the bard code with FontA
s
Add HRI characters above the bard code with FontB
t
Add HRI characters below the bard code with FontB
w
Align text to the left
x
Align text to the center
y
Align text to the right
A
Open Drawer 1 (50ms driver pulse width)
B
Open Drawer 1 (100ms driver pulse width)
C
Open Drawer 1 (150ms driver pulse width)
D
Open Drawer 1 (200ms driver pulse width)
E
Open Drawer 1 (250ms driver pulse width)
F
Open Drawer 1 without paper feeding (50ms driver pulse width)
G
Print NV bitmap image 1
H
Print NV bitmap image 2
I
Print NV bitmap image 3
J
Print NV bitmap image 4
K
Print NV bitmap image 5
P
Cut (partial cut)
R
Print the NV Graphics stored in the address 00
S
Print the NV Graphics stored in the address 01
T
Print the NV Graphics stored in the address 02

BIXOLON SRP-352plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Wi-Fi	-
Ethernet LAN	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Product color	Gray
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	200 mm
