PC/EDP and printer interface Operating instructions iS10 / iS20
56 38019417000 en
6
Continuous sending of gross/net weight with display resolution (dd resolution)
Parameter menu step 70 = 20
Gross/net weight
Time grid approx. 200 ms
Possible identifications
+ (2BH): Gross weight
, (2CH): Net weight
6.1.3 PC/EDP interface parameters
Menu call-up only via restart, see page 26.
Save data in EEPROM: Press
key.
Fig. 17: Display: "PC_Ed_P"
For input of numbers change the tens digit, see page 27.
Selection Subselection Display Explanation
or
70 00
PC/EDP interface
00
off
20
Continuous sending of weight (dd resolution)
21
MP8.4 protocol (protocol length 16 Bytes)
23
Standard dialog
24
IXNET dialog
25
IXNET dialog "WinCis" (not verifiable)
or
701 232
EDP output
232
Output via RS232
Setting changes with
each keystroke.
EtH
Output via Ethernet
