BK Precision 8500 - Command Details - CV and CW Transient Parameter Commands; Set and Read CV Transient Parameter Commands; Set CW Transient Parameter Commands

Byte
offset
Meaning
0 is CONTINUOUS
1 is PULSE
2 is TOGGLED
16-24 Reserved
0x35 Read CV mode transient parameters
Byte
offset
Meaning
3 to 6 Value A of voltage in units of 1 mV. Little-endian 4 byte number.
7 to 8 Time for A voltage in units of 0.1 ms. Little-endian 2 byte number.
9 to 12 Value B of voltage in units of 1 mV. Little-endian 4 byte number.
13 to 14 Time for B voltage in units of 0.1 ms. Little-endian 2 byte number.
15 Transient operation:
0 is CONTINUOUS
1 is PULSE
2 is TOGGLED
16-24 Reserved
0x36 Set CW mode transient power and timing
Byte
offset
Meaning
3 to 6 Value A of power in units of 1 mW. Little-endian 4 byte number.
7 to 8 Time for A power in units of 0.1 ms. Little-endian 2 byte number.
9 to 12 Value B of power in units of 1 mW. Little-endian 4 byte number.
13 to 14 Time for B power in units of 0.1 ms. Little-endian 2 byte number.
15 Transient operation:
0 is CONTINUOUS
1 is PULSE
2 is TOGGLED
16-24 Reserved
0x37 Read CW mode transient parameters
Byte
offset
Meaning
3 to 6 Value A of power in units of 1 mW. Little-endian 4 byte number.
7 to 8 Time for A power in units of 0.1 ms. Little-endian 2 byte number.
9 to 12 Value B of power in units of 1 mW. Little-endian 4 byte number.
13 to 14 Time for B power in units of 0.1 ms. Little-endian 2 byte number.
8500 DC Load Series Version: February 4, 2009 Page 58 of 76
