BK Precision 9103 User Programming Manual

#
Input Command and Return
Description
Example
1
SOUT< Output > [CR]
Return Value: [OK] [CR]
Set Output on/off.
Set Output off: < Output > =0
Set Output on: < Output > =1
Input Command: SOUT0[CR]
Return Value: [OK] [CR]
Result: Set Output off
2
GOUT[CR]
Return Value:<Output> [CR] [OK] [CR]
Get Output Status.
Output off: < Output > = 0
Output on: < Output > = 1
Input Command: GOUT [CR]
Return Value: 0 [CR] [OK] [CR]
Result: Output is off
3
VOLT< preset0/1/2/3><Voltage>[CR]
Return Value: [OK] [CR]
Set output Voltage.
*Set-Volt value relevance to preset Current
value total power<160W .Max-Volt value
refer to product specification
Input Command:
VOLT 01000[CR]
Return Value: [OK] [CR]
Result: Set Memory preset 1
voltage value is 10.00V
4
CURR< preset0/1/2/3><Current> [CR]
Return Value: [OK] [CR]
SET output Current.
* Set-Cur value relevance to preset Volt value
total power<160W .Max- Current value refer
to product specification
Input Command:
CURR 00100[CR]
Return Value: [OK] [CR]
Result: Set preset 1 Current
value is 1.00A
5
SOVP<voltage >[CR]
[Return Value:[OK] [CR]
Set Over Voltage value.
<voltage> = ????
Input Command: SOVP4200[CR]
Return Value: [OK] [CR]
Result: Set upper limit of output
Voltage 42.00V
6
GETD[CR]
Return Value: <Voltage ><Current>
<CV/CC Mode> [CR] [OK] [CR]
Get Reading Volt & Curr mode.
<voltage> = ????
< Current > = ????
<CV Mode> =0 CV Mode
<CV Mode> =1 CC Mode
Input Command: GETD [CR]
Return Value: 050001000[CR]
[OK] [CR]
Result: The Display value is
5.00V and 1.00A.
It is in CV mode.
7
SOCP<Current>[CR]
Return Value: [OK] [CR]
Set Over current value.
< Current > = ????
Input Command: SOCP1000[CR]
Return Value: [OK] [CR]
Result: Set upper limit of output
Current 10.00A
8
GOVP[CR]
Return Value: <Voltage>[CR] [OK] [CR]
Get upper limit of output Voltage.
<voltage>=????
Input Command: GOVP [CR]
Return Value: 4220 [CR] [OK]
[CR]
Result: upper limit of output
Voltage is 42.40V
9
GOCP[CR]
Return Value:<Current>[CR] [OK] [CR]
Get upper limit of output Current.
< Current >=????
Input Command: GAGA [CR]
Return Value: 1020 [CR] [OK]
[CR]
Result: upper limit of output
Current is 10.20A

BK Precision 9103 Specifications

General

Brand	BK Precision
Model	9103
Category	Power Supply
Language	English
