Operang Instrucons - BPS2000v2 Monitoring Power Distribuon Unit
6
6. BPS2000 general characteriscs
The BPS2000 monitoring device is a power distribuon device that allows monitoring electrical parame-
ters at the unit's input. It is equipped with a management module that allows supervision and control of
electrical parameters with access via a web browser. Units are available in single-phase and three-phase
designs with a load of 16A to 32A for each phase.
Units can be equipped with IEC320 C13, IEC 320 C19, NF C61-314 (st.PL/FR) or
DIN49440 (Schuko), also available with a disconnect lock for C13/C19 sockets.
Monitoring of electrical parameters at the PDU input:
• Unit power supply voltage [V]
• Total current load of the unit [A]
• Acve Power, Apparent Power, Reacve Power [kW, kVA, kVAR]
• Energy consumpon/counter of acve energy, apparent energy [kWh, kVAh]
• Power factor [PF] (cosɸ)
• Frequency [Hz]
Monitor environmental condions with dedicated sensors:
• temperature and humidity
• door opening, flooding, smoke
The unit is equipped with an interchangeable management module made with technology
"Hot Swappable." Replacement of the module does not cause interrupon of power supply to the re-
ceivers. The web interface is available from any web browser in Polish and English.
Communicaon is carried out using built-in network and communicaon protocols:
• SNMPv1/v2c/v3, Modbus RTU, Modbus TCP/IP
• HTTP, SMTP, Telnet
• IPv4/IPv6
