12.1 Modbus RTU/TCP memory map
R
Registry name
Registry address
Unit
Access
W/R
Actual value
S
Size
Decimal
Hexadecimal
Total voltage L1 00000 0x0000 V R =register/10 2 Bytes
Total voltage L2 00001 0x0001 V R =register/10 2 Bytes
Total voltage L3 00002 0x0002 V R =register/10 2 Bytes
Total current L1 00003 0x0003 A R =register/100 2 Bytes
Total current L2 00004 0x0004 A R =register/100 2 Bytes
Total current L3 00005 0x0005 A R =register/100 2 Bytes
Acve power L1 00006 0x0006 W R =register/10 2 Bytes
Acve power L2 00007 0x0007 W R =register/10 2 Bytes
Acve power L3 00008 0x0008 W R =register/10 2 Bytes
Reacve power L1 00009 0x0009 VAR R =register/10 2 Bytes
Reacve power L2 00010 0x000A VAR R =register/10 2 Bytes
Reacve power L3 00011 0x000B VAR R =register/10 2 Bytes
Apparent power L1 00012 0x000C VA R =register/10 2 Bytes
Apparent power L2 00013 0x000D VA R =register/10 2 Bytes
Apparent power L3 00014 0x000E VA R =register/10 2 Bytes
Frequency L1 00015 0x000F Hz R =register/100 2 Bytes
Frequency L2 00016 0x0010 Hz R =register/100 2 Bytes
Frequency L3 00017 0x0011 Hz R =register/100 2 Bytes
