36
Operang Instrucons - BPS2000v2 Monitoring Power Distribuon Unit
R
Registry name
Registry address
Unit
Access
W/R
Actual value
S
Size
Decimal
H
Hexadecimal
Power Factor L1 00018 0x0012 R =register/100 2 Bytes
Power Factor L2 00019 0x0013 R =register/100 2 Bytes
Power Factor L3 00020 0x0014 R =register/100 2 Bytes
Acve energy L1 00021-00024 0x0015-0x0018 kWh R =register/1000 8 Bytes
Acve energy L2 00025-00028 0x0019-0x001C kWh R =register/1000 8 Bytes
Acve energy L3 00029-00032 0x001D-0x0020 kWh R =register/1000 8 Bytes
Apparent energy P1 00033-00036 0x0021-0x0024 kVAh R =register/1000 8 Bytes
Apparent energy P2 00037-00040 0x0025-0x0028 kVAh R =register/1000 8 Bytes
Apparent energy P3 00041-00044 0x0029-0x002C kVAh R =register/1000 8 Bytes
Acve energy L1+L2+L3 00045-00048 0x002D-0x0030 kWh R =register/1000 8 Bytes
Apparent energy L1+L2+L3 00049-00052 0x0031-0x0034 kVAh R =register/1000 8 Bytes
Temperature 00053 0x0035 C R =register/10 2 Bytes
Temperature 00054 0x0036 C R =register/10 2 Bytes
Temperature 00055 0x0037 C R =register/10 2 Bytes
Humidity 00055 0x0038 % R =register/10 2 Bytes
Humidity 00056 0x0039 % R =register/10 2 Bytes
Humidity 00057 0x003A % R =register/10 2 Bytes
Door 1
59 0x003B
1=Open
2=Closed
2 Bytes
Door 2
60 0x003C
1=Open
2=Closed
2 Bytes
Modbus RTU/TCP memory map-connuaon
