Operang Instrucons - BPS2000v2 Monitoring Power Distribuon Unit
6
6.3 LCD display interface for 400V three phase version
Screen 1
Read: Phase(L1) / Load(0.0A) / Voltage(237.6V) / Acve power(0.0kW)/ Energy(000000.kWh)
Screen 2
Read: Phase(L1) / Load(0.0A) / Voltage(237.6V) / Acve power(0.0kW)/ Power factor(0.00)
Screen 3
Read: Phase(L2) / Load(0.0A) / Voltage(235.5V) / Acve power(0.0kW)/ Energy(000000.0kWh)
Screen 4
Read: Phase(L2) / Load(0.0A) / Voltage(235.4V) / Acve power(0.0kW)/ Power factor(0.00)
Screen 5
Read: Phase(L3) / Load(0.0A) / Voltage(234.9V) / Acve power(0.0kW)/ Energy(000000.0kWh)
Screen 6
Read: Phase(L3) / Load(0.0A) / Voltage(235.0V) / Acve power(0.0kW)/ Power factor(0.00)
Screen 7
Read: the IP address of the BPS2000
Screen 8
Read/write*: Master/Slave configuraon
Address: 00 indicates that the unit is in master mode
Address: 01-04 indicates that the unit is working in Slave mode from 1 to 4
Screen 9
Read/write*: Seng of threshold values, maximum
Phase(L1) / Load(16A) / Voltage(276.0V) / Temperature(40°C) / Humidity(99%)
Screen 10
Read/write*: Seng of threshold values, maximum
Phase(L2) / Load(16A) / Voltage(276.0V) / Temperature(40°C) / Humidity(99%)
Screen 11
Read/write*: Seng of threshold values, maximum
Phase(L3) / Load(16A) / Voltage(276.0V) / Temperature(40°C) / Humidity(99%)
