CHAPTER 4: CONFIGURATION
OSD
Select Configuration > User Macros in the main menu and select the user for which a user macro will be created.
FIGURE 4-27. CONFIGURATION—USER MACROS
To create a macro for the selected user, proceed as follows:
1. Select in the Key field the function key (F1–F16) for which a macro has to be created.
2. Select the position in the Key list where a macro command is to be inserted.
3. Select a macro command in the Macro Data field.
4. Set the necessary parameters P1 and P2 (e.g., CON Devices or CPU Devices) for the selected macro command.
5. Confirm your selection by pressing <Enter> and repeat the process for further macro commands, if necessary.
