CHAPTER 3: INSTA LL ATION
3.3.2 VIDEO MATRIX
If you use the Modular KVM Matrix Switch as a video matrix, up to 288 input ports can be switched to up to 288 output ports,
depending on components and equipment.
FIGURE 3-2. VIDEO MATRIX INSTALLATION EXAMPLE
TABLE 3-2. VIDEO MATRIX INSTALLATION COMPONENTS
NUMBER IN FIGURE 3-2 COMPONENT
1 Video source (e.g., SDI camera)
2 Interconnect cable
3 Modular KVM Matrix Switch
4 Video sink (e.g., monitor)
