CHAPTER 2: OVERVIEW
2.7.5 NETWORK STATUS
The current network configuration is shown in this menu.
You have the following options to access the menu:
OSD
The following information is shown in this menu:
TABLE 2-22. NETWORK CONFIGURATION
FIELD DESCRIPTION
DHCP Information whether the network settings are applied dynamically. Display Y (Yes) or N (No)
IP Address Information about the IP address as provided manually or via DHCP
Subnet Mask Information about the subnet mask as provided manually or via DHCP
Gateway Information about the gateway address as provided manually or via DHCP
MAC ID Information about the MAC address of the matrix
OSD
Select Status > Network in the main menu.
FIGURE 2-17. STATUS>NETWORK
