38
1.8 7 7. 8 7 7. 2 2 69 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.8 7 7.8 7 7.2269
CHAPTER 2: OVERVIEW
The following information is shown in the OSD menu:
TABLE 2-21. OSD MENU INFORMATION
FIELD DESCRIPTION
CON Name of console
CPU
Name of currently connected CPU
Color Coding:
Green: The connection to the selected CPU is completely established.
Yellow: The connection to the selected CPU is partially established.
Red: The connection to the selected CPU cannot be established.
NOTE: Possible reasons for any incomplete or non-established connection can be switched off extenders
or insufficiently available Grid lines in Matrix Grid operation.
ACCESS
Full Access: Console has a KVM connection to the displayed CPU.
Video Access: Console has a video only connection to the displayed CPU.
Private Mode: Console has a Private Mode connection to the displayed CPU.
not connected: Console is not connected to a CPU.
SHARED
x device(s) shows the exact number of devices that are connected to the current CPU of the console (e.g. 3 devices).
If the field remains empty, no other devices are connected to the current CPU.
NOTE: If the options Mouse Connect or Keyboard Connect are used, the name of the console with keyboard / mouse control will be
displayed on those consoles that do not have current K/M control. The console is displayed in yellow under Access.
