CHAPTER 4: CONFIGURATION
4.11.3 EXTENDER OSD
In this menu, the settings for the Extender OSD can be adjusted. These are local settings that can be made individually
for each console.
You can select the following Extender OSD settings.
TABLE 4-42. EXTENDER OSD SETTINGS
FIELD SELECTION DESCRIPTION
Enable CPU Selection List
activated
When executing the key sequence for opening the OSD, a selection list for switching
CPU Devices will be displayed in the center of the monitor. Pressing the <F7> button
within the selection list opens the standard OSD.
deactivated Function not active (default)
Enable Connection Info
activated Enable Extender OSD (default: YES)
deactivated Function not active
Update Connection Info
activated Update connection changes during fade-in of Extender OSD (default: YES)
deactivated Function not active
Display Time 0–999 seconds Duration of OSD fade-in (default: 10)
Horizontal Position 10 pixels Horizontal OSD position (default: -2)
Vertical Position 10 pixels Vertical OSD position (default: 2)
NOTE: When setting the horizontal OSD position, a prefixed minus describes the orientation to the right edge of the monitor,
e.g. -2 means 2 x 10 = 20 pixels to this edge. When setting a vertical position, a prefixed minus describes the orientation
to the bottom edge of the monitor.
If the Update Connections function is deactivated, the Extender OSD only appears when switching via OSD.
You have the following options to access the menu.
OSD
