CHAPTER 4: CONFIGURATION
JAVA TOOL
Select Definition > EXT Units in the task area.
FIGURE 4-30. DEFINITION—EXT UNITS
You can select the following buttons.
TABLE 4-30. BUTTONS
BUTTON FUNCTION
New Create a new extender unit
Delete Delete an existing extender unit
Apply Confirm changes of an extender unit
Cancel Reject changes
FLEXIBLE PORT EXTENDER UNITS
Extenders with auto-ID functionality are automatically recognized and cannot be created manually. This is the Flex Port function
of the matrix.
CAUTION: The connection of a fixed port extender unit (e.g., USB 2.0) to a Flex-Port can cause unintended results.
