CHAPTER 4: CONFIGURATION
4.11.5 CONSOLE MACROS
In this menu, macro commands for switching, disconnection or user administration can be created. The macro commands
are created for each console separately.
A macro can execute up to 16 switching commands successively.
The execution of the macros is done via hotkey and the function keys <F1>-<F16> (see Section 5.1.3).
You can select the following settings.
TABLE 4-43. CONSOLE MACROS SETTINGS
FIELD SELECTION DESCRIPTION
Function (01–16)
Connect
(P1 = CON, P2 = CPU)
Set bidirectional connection from console P1 to CPU P2
Connect Video
(P1=CON, P2=CPU)
Set video connection from console P1 to CPU P2
Disconnect (P1=CON) Disconnect console P1
Logout User Logout current user
Set Real CPU
(P1=VCPU, P2=RCPU)
Assign a virtual CPU to a real CPU
Set Virtual CON
(P1=RCON, P2=VCON)
Assign a real console to a virtual console
Push (P1=CON)
The user’s KVM connection is forwarded to console P1 and is changed to a video only
connection.
Push Video (P1=CON)
The video signal of the current connection (KVM or video only) is forwarded to console
P1. The user’s connection remains unchanged (KVM or video only).
Get (P1=CON)
The console gets a KVM connection to the CPU that is currently connected to console
P1. The connection of console P1 is changed into a video only connection.
Get Video (P1=CON)
The console gets a video only connection to the CPU that is currently connected to
console P1. The connection of console P1 remains unchanged (KVM or video only).
Login User Login a certain user P1 at console P2
P1 CON or CPU Device Name of CON or CPU Device
P2 CPU or CPU Device Name of CPU or CPU Device
You have the following options to access the menu.
OSD
