CHAPTER 4: CONFIGURATION
OSD
Select via Configuration > CON Macros in the main menu the console for which a console macro is to be created.
FIGURE 4-47. CONFIGURATION—CON MACROS
To create a macro for the selected console, proceed as follows:
1. Select in the Key field the function key (F1-F16) for which a macro should be created.
2. Select the respective place on the list (1-16) the key that should be set with a macro key.
3. Select for the highlighted position on the list a macro command in the Macro Data field.
4. Set the necessary parameters P1 and P2 (e.g. CON Devices or CPU Devices) for the selected macro command.
5. Confirm your inputs by pressing <Enter> and repeat the process for further macro commands, if necessary.
