CHAPTER 4: CONFIGURATION
JAVA TOOL
 Select Definition > CPU Devices in the task area.
FIGURE 4-38. DEFINITION—CPU DEVICES
You can select the following buttons.
TABLE 4-33. BUTTONS
BUTTON FUNCTION
New Open a new CPU device
Delete Delete a new CPU device
Apply Confirm a created CPU device
Cancel Reject changes
> Assign selected extender units
>> Assign all available extender units
< Remove selected extender units
<< Remove all extender units
You can select the following keyboard commands.
TABLE 4-34. KEYBOARD COMMANDS
FUNCTION KEYBOARD COMMAND
Change assignment number of EXT unit upwards <+>
Change assignment number of EXT unit downwards <->
