CHAPTER 4: CONFIGURATION
FIGURE 4-69. ADMINISTRATION—UPDATE EXT FIRMWARE
2. Set the matrix into Service Mode upon request in the popup window or via Matrix > Activate Service Mode in the menu bar.
During activation, all matrix functions are disabled on the I/O boards on which an update is currently performed. An OSD picture
indicates the activation of the Service Mode and is displayed on all monitors that are connected to the matrix via a CON device.
In addition, the Service Mode is indicated by a red tool icon in the lower part of the working area.
FIGURE 4-70. OSD VIEW—SERVICE MODE
3. Start the update by pressing the Update button in the lower part of the working area.
