CHAPTER 2: OVERVIEW

TABLE 2-5. 576-PORT CHASSIS FRONT VIEW COMPONENTS

NUMBER IN FIGURE 2-2 COMPONENT

1 Grounding

2 Slot for power supply unit 1

3 Slot for power supply unit 2

4 Slot for fan tray 1

5 Slot for fan tray 2

6 Slot for power supply unit 3

7 Slot for I/O boards

8 Slot for CPU board
