CHAPTER 2: OVERVIEW
JAVA TOOL
To activate the SNMP agent, proceed as follows:
1. Select System > Network in the task area.
FIGURE 2-24. SYSTEM—NETWORK
2. Activate the SNMP Agent option in the SNMP tab. By activating this option, the permission for an active query of the SNMP
agent is granted.
To configure an SNMP server, proceed as follows:
Select Configuration > Network in the task area.
Activate the Enable Traps option within SNMP Server. This function allows an active transmission of trap messages from the SNMP
agent to the SNMP server.
Set the IP address of the SNMP within SNMP Server.
Activate the requested traps.
NOTE: To activate the SNMP agent function or the SNMP server function, you must restart the matrix.
