VESA MOUNTING BRACKET OVERVIEW
PRINTED N OVEMBER 3, 2009
1-4
For Unattended use, the mounting position can be fixed by placing the lock screws in the position shown
below. This locked position conceals the cables from sight, and secures them from being tampered with.
Figure 1-6 VESA Bracket Screw Position - Unattended
Assembly Details
Figure 1-7 VESA Bracket Assembly Details
Base extensions
Locking screws
Pivot Plate
Base
Cable Holes
