M ULTI-FUNCTION READER MF4100 INSTALLATION GUIDE
D OCUMENT 1295 REV 01
PRINTED N OVEMBER 3 , 2 0 0 9 1-5
MOUNT THE MF4100
MF4100 MOUNTING OPTIONS:
• Wall Mount Installation (Page: 6)
•
Table Top Mount Installation (Page: 10)
Figure 1-8 Wall Mount Options
Figure 1-9 Table Top Mount Options
Unattended wall mountAttended wall mount
Fixed 15 degree angle Adjustable angle No VESA bracket
