Operating Your ATEM Switcher
57
To perform a graphic transition on the broadcast panel
Step 1. Select DVE as the transition type by pressing the SHIFT and DVE/WIPE buttons simultaneously.
The DVE is illuminated green indicating that the DVE transition type is selected.
If the DVE is already being used in an upstream key, the message DVE unavailable will be
displayed and the DVE transition type will be unavailable for selection until the key is taken
off air and off preview. Refer to sharing DVE resources below for more information.
Step 2. From the system control menu buttons, push next until you are on the DVE Graphics menu,
You can also navigate to the DVE menu by selecting TRANS > DVE PATTRN from the home
menu and pushing next to get to the DVE Graphic page.
Step 3. Select one of the two graphic mix buttons, depending on which way you want your graphic
to spin across the screen.
Step 4. Select the logo fill source and logo key source for the graphic from the select bus.
Step 5. Set the rate and any other key parameters if required.
Step 6. Perform the transition as an auto transition or manual transition from the transition control
block.
Description of graphic wipe parameters
Fill Source
The fill signal is the color graphic you will use on top of the transition.
Key Source
The key signal is a grayscale image that defines the region in the graphic that will
be removed so that the fill signal can be correctly stacked on top of the wipe.
Normal
The normal direction moves the graphic from left to right.
Reverse
Reverse changes the direction so that is moves the graphic from right to left.
FlipFlop
When FlipFlop mode is toggled on, the transition changes between normal and
reverse every time the transition is executed. The normal or reverse light indicates
the direction of the next transition.
Rate
Rate specifies the length of the transition in seconds and frames. The rate can be
adjusted using the rate knob or by entering a number on the number pad and
pressing the set rate button.
