Check list
Read carefully the safety information in the user manual. Before starting up the drive, please check the following points regarding
mechanical and electrical installations, then use and run the drive.
For complete documentation, refer to www.blemo.com.
1. Mechanical installation
• For drive mounting types and recommendations on the ambient temperature, please refer to the Mounting and temperature conditions
instructions on page 12
.
• Mount the drive vertically as specified, see Mounting and temperature conditions instructions on page 12
.
• The use of the drive must be in agreement with the environments defined by the standard 60721-3-3 and according to the levels
defined in the catalogue.
• Mount the options required for your application, refer to the catalogue.
2. Electrical installation
• Connect the drive to the ground, see Equipment grounding on page 15.
• Ensure that the input power voltage corresponds to the drive nominal voltage and connect the line supply as shown in General wiring
diagram on page 17
.
• Ensure you use appropriate input power fuses and circuit breaker on page 99
• Wire the control terminals as required, see Control terminals on page 22. Separate the power cable and the control cable according
to the EMC compatibility rules on page 25
.
• The ER12-...K/B range integrates an EMC filter. The leakage current can be reduced using the IT jumper as explained in the
paragraph Internal EMC filter on ER12-...K/B on page 27
.
• Ensure that motor connections correspond to the voltage (star, delta).
3. Use and run the drive
• Start the drive and you will see Standard motor frequency bFr page 44 at the first power on. Check that the frequency defined by the
frequency bFr (the factory setting is 50 Hz) is in accordance with the frequency of the motor, see First power-up on page 33
.
For the following power on, you will see rdY on the HMI.
• MyMenu (upper part of CONF mode) allows you to configure the drive for most applications (see page 44
).
• Factory / recall customer parameter set FCS function page 45
allows you to reset the drive with factory settings.
