BLEMO ER12 - Setup - Preliminary Recommendations; Pre-Operation and Configuration Guidelines

10
Drive ratings
Single-phase supply voltage: 100…120 V 50/60 Hz
For three Phase Output 200/240 V motors
Single-phase supply voltage: 200…240 V 50/60 Hz
For three Phase Output 200/240 V motors
Three-phase supply voltage: 200…240 V 50/60 Hz
For three Phase Output 200/240 V motors
Motor Line supply (input) Drive (output) Reference
Power indicated
on plate (1)
Maximum line current Apparent
power
Power
dissipated
at nominal
current (1)
Nominal
current
In
Max. transient
current for
at 100 V at 120 V
60 s 2 s
kW HP A A kVA W A A A
0.18 0.25 6 5 1 18 1.4 2.1 2.3 ER12-0.18KU
0.37 0.5 11.4 9.3 1.9 29 2.4 3.6 4 ER12-0.37KU or BU
0.75 1 18.9 15.7 3.3 48 4.2 6.3 6.9 ER12-0.75KU
Motor Line supply (input) Drive (output) Reference
Power indicated
on plate (1)
Maximum line current Apparent
power
Power
dissipated
at nominal
current (1)
Nominal
current
In
Max. transient
current for
at 200 V at 240 V 60 s 2 s
kW HP A A kVA W A A A
0.18 0.25 3.4 2.8 1.2 18 1.4 2.1 2.3 ER12-0.18K
0.37 0.5 5.9 4.9 2 27 2.4 3.6 4 ER12-0.37K or B
0.55 0.75 8 6.7 2.8 34 3.5 5.3 5.8 ER12-0.55K or B
0.75 1 10.2 8.5 3.5 44 4.2 6.3 6.9 ER12-0.75K or B
1.5 2 17.8 14.9 6.2 72 7.5 11.2 12.4 ER12-1.5K or B
2.2 3 24 20.2 8.4 93 10 15 16.5 ER12-2.2K or B
Motor Line supply (input) Drive (output) Reference
Power indicated
on plate (1)
Maximum line current Apparent
power
Power
dissipated
at nominal
current (1)
Nominal
current
In
Max. transient
current for
at 200 V at 240 V 60 s 2 s
kW HP A A kVA W A A A
0.18 0.25 2 1.7 0.7 16 1.4 2.1 2.3 ER12-0.18/3K
0.37 0.5 3.6 3 1.2 24 2.4 3.6 4 ER12-0.37/3K or B
0.75 1 6.3 5.3 2.2 41 4.2 6.3 6.9 ER12-0.75/3K or B
1.5 2 11.1 9.3 3.9 73 7.5 11.2 12.4 ER12-1.5/3K or B
2.2 3 14.9 12.5 5.2 85 10 15 16.5 ER12-2.2/3K or B
3 4 19 15.9 6.6 94 12.2 18.3 20.1 ER12-3.0/3K or B
4 5.5 23.8 19.9 8.3 128 16.7 25 27.6 ER12-4.0/3K or B
(1)These power ratings are for a switching frequency of 4 kHz, in continuous operation. The
switching frequency is adjustable from 2 to 16 kHz.
Above 4 kHz, the drive will reduce the switching frequency if an excessive temperature rise
occurs. The temperature rise is detected by a probe in the power module. Nonetheless,
derating should be applied to the nominal drive current if continuous operation above 4 kHz
is required:
• 10% derating for 8 kHz
• 20% derating for 12 kHz
• 30% derating for 16 kHz
