BLEMO ER12 - Monitoring Mode Mon

37
Monitoring mode MOn
When the drive is running, the value displayed is that of one of the monitoring parameters. The default value displayed is the motor Output
frequency rFr page 38
.
While the value of the desired new monitoring parameter is being displayed, press a second time on the jog dial button to display the units.
Organization tree
(1) Depending on reference channel active.
Possible values:
LFr
AIU1
(2) 2 sec or ESC
Displayed parameter values and units of the diagram are given as
examples.
values
units
