Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
I_O-
Input Output menu (continued)
AO1-
AO1 configuration menu
AO1
• AO1 assignment
nO
nO
OCr
OFr
OrP
OPS
OPF
OPE
OPr
tHr
tHd
This parameter is used to set the value of an analog output.
• Not assigned
• Motor current
• Output frequency
• Ramp output
• PID reference - Visible only if PID feedback assignment PIF page 70 is not set to nO
• PID feedback - Visible only if PID feedback assignment PIF page 70 is not set to nO
• PID error - Visible only if PID feedback assignment PIF page 70 is not set to nO
• Output power
• Motor thermal state
• Drive thermal state
AO1t
• AO1 type
0A
10U
OA
4A
This parameter provides the interface between the drive internal value and an analog output signal.
• Voltage: 0-10 Vdc
• Current: 0-20 mA
• Current: 4-20 mA
