68
Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
PSS-
Preset speed menu
PS2
• 2 Preset speeds
nO
nO
L1H
L2H
L3H
L4H
• Function inactive
• L1h: LI1 active high
• L2h: LI2 active high
• L3h: LI2 active high
• L4h: LI4 active high
PS4
• 4 Preset speeds
nO
as PS2
PS8
• 8 Preset speeds
nO
as PS2
SP2
• Preset speed 2
0 to 400 Hz 10 Hz
Visible only if 2 Preset speeds PS2 is not set to nO.
SP3
• Preset speed 3
0 to 400 Hz 15 Hz
Visible only if 4 Preset speeds PS4 is not set to nO.
SP4
• Preset speed 4
0 to 400 Hz 20 Hz
Visible only if 2 Preset speeds PS2 and 4 Preset speeds PS4 are not set to nO.
SP5
• Preset speed 5
0 to 400 Hz 25 Hz
Visible only if 8 Preset speeds PS8 is not set to nO.
SP6
• Preset speed 6
0 to 400 Hz 30 Hz
Visible only if 2 Preset speeds PS2 and 8 Preset speeds PS8 are not set to nO.
SP7
• Preset speed 7
0 to 400 Hz 35 Hz
Visible only if 4 Preset speeds PS4 and 8 Preset speeds PS8 are not set to nO.
SP8
• Preset speed 8
0 to 400 Hz 40 Hz
Visible only if 2 Preset speeds PS2, 4 Preset speeds PS4 and 8 Preset speeds PS8 are not set to nO.
JPF
• Skip frequency
0 to 400 Hz 0 Hz
• This parameter prevents prolonged operation within an adjustable range around the regulated frequency.
This function can be used to prevent a critical speed, which would cause resonance, being reached. Setting
the function to 0 renders it inactive.
Parameter that can be modified during operation or when stopped.
I-O-
drC-
CtL-
FUN-
FLt-
COM-
