8
Size:
Models BD8-502, BD8-503
Height: 21” Width: 18.5” Length (depth): 14.5”
Limitations:
Volume Limited - Models BD8-502, BD8-503
Products other than those dispensed by the unit (ice cream, yogurt, etc.) can
be added to the blending jar before dispensing. This limits the finished drink
size to 32 ounces.
Section 3: Installation
Read all instructions, cautions, notes, and warnings before attempting to
operate this machine. Warranties may be voided if this machine is improperly
installed.
3.1 Counter Placement:
Ensure there are at least 4 inches of space on each side and at least 6 inches
in back (room for plumbing). Counter location should be near water, ice, and
storage area for product bags.
3.2 Electrical Connections:
See power requirements in section 1.14.
3.3 Water Connection:
A 3/8” compression fitting is located behind the (optional) vanity panel in
the upper right-hand corner (from the rear of the machine). You must use a
reinforced water line with this unit. Incoming water must have a pressure rating
of at least 30 PSI (207 KPA) and no greater than 120 PSI (827 KPA) to operate
correctly. You must add a water filter with a flow rate of at least 1 gallon per
minute (3.78 Liters per minute). Unit must be installed with adequate back-flow
protection to comply with Federal, state, or local codes having jurisdiction.
3.4 Product Lines and Connections:
The inlets for the product lines are located on the back of the unit. There are
labels next to each inlet with numbers that correspond to the pump numbers
in programming. These fittings are ⅜” outer diameter and are barbed to help
retain the hose. Use a hose clamp to retain the hose on the inlet fitting.
Section 4: Basic Operations
4.1 Making Drinks:
Place a blender jar containing sufficient ice in the blend station with the blend-
er lid in place. After programming drinks into the microprocessor (see Section
6), you simply press the drink number (1-64) of the drink, select the size (S,
M, or L), and then press GO. The unit will automatically dispense liquids and
