8
•
Read all the instructions before using and installing this product.
•
Do not use this product if power cable or charging cable have any damage.
•
Do not use this product if the enclosure or charging connector are broken or
open or if there is damage.
•
Do not put any tool, material, finger or other body part into the charging connec -
tor or EV connector.
•
•
•
Power feed must be 3 Phase Wye configuration with TN(-S)/TT grounding sys -
tems.
•
In the installation of TN(-S) system: the neutral (N) and the PE of the power dis -
tribution are directly connected to the earth. The PE of the charger equipment is
directly connected to the PE of power distribution and separate conductor for PE
and neutral (N).
•
In the installation of TT system: the neutral (N) and the PE of the power distribu -
tion are directly connected to the earth. The PE of the charger equipment is iso -
lated to the PE of power distribution to the earth.
•
The capacity of power supply should be higher than 33.0kVA in order to function
correctly.
•
The product should be installed in free air area and keep at least 30cm clearance
distance to all air vent of the product.
•
Need sufficient space for product installation and maintenance, please keep not
less than 60cm clearance distance from all around the product.
3. Installation Instruction
3.1 Before Installation
Warning:
The product should be installed only by a licensed contractor
and/or licensed technician in accordance with all building codes, elec -
trical codes and safety standards.
Warning:
The product should be inspected by a qualified installer prior
to initial use. Under no circumstances will compliance with the infor -
mation in this manual relieve user of his /her responsibilities to comply
with all applicable codes and safety standards.
