Blink SemaConnect US - DW30 Version Description; LED Indication and Operation Status

5
2.2 LED Indication and Operation Status
Status LED Left Indicator Right Indicator
Standby Green Green
Fault Red Red
Charging Blue Blue
2.2 DW30 Version Description
The DW30 seriers are available in different versions depending on the charging
connectors, below table shows the available combinations, the coresponding posi -
tion of charging connectors are indicated from left to right in the view of front char -
ger.
Version CHAdeMO CCS1
DWWx301 J0U
X
X
DWWx301 J00
X
-
DWWx301 U00
-
X
0 : none
1 : IEC 62196-2 Type 1/SAE J1772 Plug
2 : IEC 62196-2 Type 1/SAE J1772 Socket
3 : IEC 62196-2 Type 2 Plug
4 : IEC 62196-2 Type 2 Socket
5 : GB/T AC Plug
6 : GB/T AC Socket
7：CCS2 AC Plug
J : CHAdeMO
U : Natural cooling CCS1 combo
V : Liquid cooling CCS1 combo
E : Natural cooling CCS2 combo
F : Liquid cooling CCS2 combo
G : GBT DC
