Blink SemaConnect US - Basic User Interface

1. Basic User Interface
Antenna
Indication Light
7" Information Screen
Right Button
Left Button
RFID Card Reader
•
Charging Status
•
Alarm information
•
User Authorization
Key Switch (Power On/Off)
Emergency Stop
USB Port
RJ45 Port
Charging Cable Outlet
Charging Cable Outlet
AC Cable Inlet
Main unit :
Notice: According to EN-17186 requirement, this
document lays down harmonized identifiers for pow -
er supply for electric road vehicles. The requirements
in this standard are to complement the informational
needs of users regarding the compatibility between
the EV charging stations, the cable assemblies and
the vehicles that are placed on the market. The
identifier is intended to be visualized at EV charging
stations, on vehicles, on cable assemblies, in EV
dealerships and in consumer manuals as described.
2
semaconnect.com
