3
Model Name DWWx301 Series
AC
INPUT
Voltage Rating 3
Φ
480 Vac (+10%, -15%).
Input current 40A
Electrical Distribution 3P+ N +PE (Wye Configuration)
Power Grid System TN / TT
Frequency 50/60Hz
Max. Input Power 33 kVA
Power factor > 0.99
Efficiency > 94%
DC
OUTPUT
Output voltage range
CHAdeMO: 150 ~ 500 Vdc
CCS1: 150 ~ 950 Vdc
Max. output current
CHAdeMO & CCS1: 500Vdc@60A
CCS1: 950Vdc@31.5A
Max. output power 30kW
Voltage accuracy +/- 2%
Current accuracy +/- 2%
User Interface
Display 7-inch LCD
Button
Right Button : Select charging
connector. (*Not applicable to this
model)
Left Button : Home / Stop charge
User Authorization
RFID: support ISO 14443A/B, ISO
15693, FeliCa Lite-S (RCS966)
OCPP, 2D barcode, APP, Mobile
Payment
Backend support OCPP 1.6JSON
Display information
*Charging process and status
*Status codes
Electrical Isolation Isolation between input and output
Standby Power < 100W
