16
Four screws of the Gun Holder must be disassembled at the circles below
outlined.
STEP 1.
Gun Holder screw location
The hole position of the Gun Holder
Unit: mm
Installing the Gun Holder
etairporppa eht ta esab redloH nuG ecalp dna revoc redloH nuG eht evomeR
height between 600mm (24 inches) and 1.2m (4 feet), and then attach 2 pcs
5/16ā expansion screws to the Gun Holder base, then assembly the cover
back.
STEP 2.
Gun Holder screw location
120
