ELECTRIC CONVECTION OVENS 7 INSTALLATION
UTILITY CONNECTION
CTB & CTBR
VOLTAGE
KW
PHASE
MAX LOAD (AMPS) ELECTRICAL CONNECTION
AWG*
L1 L2 L2 N
60 HZ
208 5.6 1 27 — 27 — 8
5.6 3 24 12 15 — 10
6.8 1 33 — 33 — 6
6.8 3 20 18 19 — 10
8.0 1 35 — 35 — 6
8.0 3 22 20 21 — 10
220-240 5.6 1 24 — 24 — 8
5.6 3 21 11 14 — 10
6.8 1 28 — 28 — 6
6.8 3 18 16 17 — 10
8.0 1 32 — 32 — 6
8.0 3 20 18 19 — 10
50 HZ
220-240 5.6 1 24 — — 24 Size per local codes
6.8 1 28 — 28 —
8.0 1 35 — — 35
240/415 5.6 3 11 0 9 3 Size per local codes
6.8 3 11 9 9
8.0 3 13 11 11 2
230/400 5.6 3 11 0 10 1 Size per local codes
6.8 3 11 9 9
8.0 3 13 11 11 2
* Electric connection wiring is sized for 90ºC copper wire at 125% of rated input.
NOTE: Double units can have phase loads partially equalized by matching lines during hook-up. Otherwise, CTB-Double
or CTBR-Double load ratings are twice the above data.
