Patient Monitor User’s Manual

9-3

instructions for use.

④ Test the earth leakage current according IEC 60601-1 Limit:

NC 500μA, SFC: 1000μA.

⑤ Test the enclosure leakage current according to IEC 60601-1:

Limit: NC 100μA, SFC: 500μA.

⑥ Test the patient leakage current (normal operation) according

IEC 60601-1

Limit: type CF: for a.c.: 10μA, for d.c.: 10μA.

⑦ Test the patient leakage current under single fault condition

according IEC 60601-1

Limit: type CF: for a.c.: 50μA, for d.c.: 50μA.

⑧ Test the patient leakage current Mains voltage on applied

part: According IEC 60601-1:

Limit: type CF: for a.c.: 50uA.

Warning: No use-serviceable parts inside, before

servicing to authorized representative or

manufacturer.
