141
AT6020
StripTill Residue Manager
Bundle Number
70210646
BOM ID Qty Item No Description
1 1 AM2489 CLEVIS, SEALER SPRING, LOWER
2 1 AM2490 TUBE, UPPER SPRING
3 1 AM2491 BUSHING, SPRING COLLAR
4 1 AM2492 TUBE, SPRING GUIDE
5 1 AM7662 RESIDUE MANAGER BLADE, LEFT HAND
6 1 AM7663 RESIDUE MANAGER BLADE, RIGHT HAND
7 1 AM7667 BRACKET, PIVOT ARM/ SPRING MOUNT, RESIDUE MANAGER
8 1 AM7669 BRACKET, ARM STOP, RESIDUE MANAGER
9 2 AM7670 ASSEMBLY, BLADE MOUNTING, RESIDUE MANAGER
10 1 AM7671 MOUNT ARM WITH PIVOT TUBE, BOLT ON BLADE MOUNT, RESIDUE MANAGER
11 1 AP2997W SPRING, 1.75” OD X 1.313” ID X 6.00”
12 1 AP3116 TUBE PLUG
13 4 BP3003 NUT, HEX LOCK, 3/8”-16, GRADE 2, PLATED
14 4 BP3005 HEX CAP SCREW, 3/8”-16 X 1-1/2”, GRADE 5, PLATED
15 1 BP3041 HEX CAP SCREW, 1/2”-13 X 2”, GRADE 5, PLATED
16 5 BP3050 WASHER, FLAT, 1/2”, PLATED
17 1 BP3125 HEX CAP SCREW, 1/2”-13 X 1”, GRADE 5, PLATED
18 1 BP3126 HEX CAP SCREW, 1/2”-13 X 1-1/2”, GRADE 5, PLATED
19 1 BP3128 HEX CAP SCREW, 1/2”-13 X 2-1/2”, GRADE 5, PLATED
20 1 BP3129 HEX CAP SCREW, 1/2”-13 X 3”, GRADE 5, PLATED
21 1 BP3130 HEX CAP SCREW, 1/2”-13 X 3-1/2”, GRADE 5, PLATED
22 1 BP3162 PIN, ROLL, 3/8” X 2”, PLATED
23 6 BP3244 NUT, HEX LOCK, 1/2”-13, PLATED
24 2 BP3249 MACHINERY BUSHING, 1-7/8” OD X 1-1/4” ID, 14 GAUGE, PLATED
25 10 BP3366 HEX FLANGE BOLT, 1/4”-20 X 3/4”, GRADE 8, PLATED
26 10 BP3367 NUT, HEX FLANGE, 1/4”-20, SERRATED, GRADE 2, PLATED
