42
AT6020
Center Section Area of Bundle 66000103
BOM ID Qty Item No Description
1 1 66000103 AT6020 MAIN FRAME & PRIMARY WINGS
4 11 AAM2438 HOSE RETAINER ASSEMBLY, CLOSED LOOP, 6X6 TUBE
4A 11 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
4B 22 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
4C 22 BP3002 WASHER, LOCK, 3/8”, PLATED
4D 11 BP3351 U-BOLT, 3/8”-16 X 6W X 7L, PLATED
14 3 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
32 1 AM6172 FRAME, MAIN, AT6020
32A 1 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
33 4 AM6179 LINKAGE, CYLINDER LUG SUPPORT
38 2 AM6202 CYLINDER LUG, BOLT-ON W/ NOTCH
38A 2 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
44 4 AP2215 DECAL, BLU-JET, 3 X 8
65 2 BM3664 PIN, 1-3/4” X 16-9/16” OAL, W/ 21/32” HOLE
66 12 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
67 12 BP3002 WASHER, LOCK, 3/8”, PLATED
69 6 BP3005 HEX CAP SCREW, 3/8”-16 X 1-1/2”, GRADE 5, PLATED
72 14 BP3019 NUT, HEX, 1”-8, GRADE 2, PLATED
73 6 BP3020 WASHER, LOCK, 1, PLATED
88 6 BP3135 HEX CAP SCREW, 5/8”-11 X 3-1/2”, GRADE 5, PLATED
95 4 BP3200 HEX CAP SCREW, 1”-8 X 3-1/2”, GRADE 5, PLATED
96 8 BP3205 MACHINERY BUSHING, 2-1/2” OD X 1-3/4” ID, 10GA, PLATED
101 6 BP3291 HEX CAP SCREW, 1”-8 X 4”, GRADE 5, PLATED
106 10 BP3375 NUT, HEX LOCK, 5/8”-11, NYLOCK
113 1 DP4484 REPHASING CYLINDER, 3-1/2” X 12”, PMS-AM-2564
114 1 EM3735 BUSHING
