48
AT6020
Primary Wing Left-hand Area of Bundle 66000103
Tractor Side
BOM ID Qty Item No Description
4 11 AAM2438 HOSE RETAINER ASSEMBLY, CLOSED LOOP, 6X6 TUBE
4A 11 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
4B 22 BP3001
NUT, HEX, 3/8”-16,
GRADE 2, PLATED
4C 22 BP3002 WASHER, LOCK, 3/8”, PLATED
4D 11 BP3351 U-BOLT, 3/8”-16 X 6”W X 7”L, PLATED
14 3 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
15 2 AM4415 HOSE RETAINER, OPEN LOOP
16 2 AM4442 HOSE RETAINER, CLOSED LOOP
19 2 AM4517 WING LOCK
20 2 AM4524 ROCKER, AT6020
20A 4 BP3072 GREASE ZERK, 1/4”-28
20B 2 BP3560 TENSION BUSHING, 1-1/2”X 1-1/4” X 1” OAL
22 2 AM4529 SAFETY LAUNCH TRIP, PRIMARY WING, AT 5000
24 2 AM4564 CYLINDER LUG, SCREW ADJUST
24A 2 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
25 2 AM4566 WING LATCH PIVOT, SECONDARY WING
26 2 AM4567 SPACER PIPE, 6-1/4” OAL
27 4 AM4568 SECONDARY WING LOCK PLATE
30 1 AM6163 WHEEL LEG, LH, W/ 2-3/4” SPINDLE LOOP
To Next Page
