90
AT6020
Hitches
1
Ref. Part No. Req. Description
1. AM2144 1 Fabricated Truck Hitch
1
AP3127 Perfect Hitch Assembly CATEGORY IV-V
AAM2424 HITCH STORAGE BRACKET
BOM ID Qty Item No Description
1 1 AM2145 BRACKET, HITCH STORAGE, 6” MOUNTING
2 2 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
3 2 BP3002 WASHER, LOCK, 3/8”, PLATED
4 1 BP3045 U-BOLT, 3/8”-16 X 6”W X 5”L
5 1 BP3500 PIN, HAIR CLIP, 3/16”
BOM ID Qty Item No Description
1 1 AP3123 PERFECT HITCH, CATEGORY V, BLACK
2 1 AP3125 CATAGORY V TO CATEGORY IV ADJUSTER PLATE, AP4-5P
3 1 AP3126 SPRING, PERFECT HITCH ADAPTER, PMI-136
4 1 BP3524 WASHER, FLAT, 5/8”, PLATED
5 1 BP3743 BOLT, CARRIAGE, 5/8”-11 X 4”, GRADE 5, PLATED
6 1 BP3744 NUT, HEX LOCK, 5/8”-11, GRADE 5, PLATED, TOPLOCK
To Next Page
