159
AT6020
AAM2707 Hub and Spindle Assembly
511 Hub, 1-3/4” x 13” Spindle
AAM2707, 511 HUB, 1-3/4” X 13” SPINDLE ASSEMBLY
BOM ID Qty Item No Description
1 1 AP2023 BEARING CONE, LM 67048
2 1 AP2024 BEARING CONE, LM 11949
3 1 AP2029 PIN, COTTER, 5/32 X 1-1/2”
4 5 AP2049 WHEEL BOLT, 1/2”-20 X 1”
5 1 AP2052 GREASE SEAL, CR 14974
6 1 AP2053 HUB CAP, 1524
7 1 AP2124 HUB WITH CUPS, 5 BOLT, 511300-5
7A 1 AP2075 BEARING CUP, LM 11910
7B 1 HUB HUB,5 BOLT, 5.5” BOLT CIRCLE, 4” PILOT
7C 1 AP2524 BEARING CUP, LM 67010
8 1 AP2169 SPINDLE, 1-3/4” X 13”, S7151-H-00
9 1 AP2704 NUT, SPINDLE, 3/4”-16
10 1 AP2705 WASHER, SPINDLE, 1-1/2” X 13/16” X .134”
