BLU-JET AT6020 - Page 73

71
AT6020
66000108 Third Wing Left Side
Third Wing Left Side Bundle 66000108
BOM ID Qty Item No Description
1 1 AM6166 WING, THIRD, LEFT HAND
2 1 AM3601 LINKAGE, WING FOLD, DOUBLE
2A 1 BP3072 GREASE ZERK, 1/4”-28
3 1 AM3602 LINKAGE, WING FOLD, SINGLE, 11-3/4”
3A 2 BP3072 GREASE ZERK, 1/4”-28
4 1 AM6154 THIRD WING CYLINDER LUG & SADDLE
5 2 BP3205 MACHINERY BUSHING, 2-1/2” OD X 1-3/4” ID, 10 GAUGE
6 1 BM3461 PIN, 1-3/4” X 19-3/4” OAL, WITH 21/32” HOLE, PLATED
7 1 AM6155 WING LATCH MOUNTING, LEFT HAND
8 1 AM6157 WING LATCH HOOK, THIRD WING
9 1 AM6205 WING LATCH, THIRD WING, LEFT HAND
10 1 BM3543 PIN, 1” X 4-5/16” DOUBLE GROOVED, PLATED
11 2 BP3215 MACHINERY BUSHING, 1-1/2” OD X 1” ID, 14 GAUGE, PLATED
12 2 AP2407 SNAP RING, 1” EXTERNAL, HEAVY DUTY
13 1 BP3135 HEX CAP SCREW, 5/8”-11 X 3-1/2”, GRADE 5, PLATED
14 1 BP3375 NUT, HEX LOCK, 5/8”-11, NYLOCK
15 1 BP3143 HEX CAP SCREW, 3/4”-10 X 4”, GRADE 5, PLATED
16 1 BP3027 NUT, HEX LOCK, 3/4”-10, GRADE 2, PLATED
17 3 BP3350 U-BOLT, 3/4”-10 X 6”W X 7-11/16”L, PLATED
18 3 BP3354 U-BOLT, 5/8”-11 X 4” X 7-3/4”, PLATED
19 6 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
20 6 BP3038 NUT, HEX, 5/8”-11, GRADE 2
21 6 BP3035 WASHER, LOCK, 3/4”, PLATED
22 6 BP3039 WASHER, LOCK, 5/8”, PLATED
23 1 BM3563 PIN, 1” X 7” OAL, WITH 13/32” HOLE
24 1 BP3115 HEX CAP SCREW, 3/8”-16 X 2”, GRADE 5, PLATED
25 1 CP2660 NUT, HEX LOCK, 3/8”-16, NYLOCK
26 1 66000102L SWING ADJUST GAUGE WHEEL, LEFT SIDE
26A 1 AM6186 BRACKET, MOUNTING, 6”, SWING ADJUST GAUGE WHEEL
26B 1 AM7581 WHEEL LEG, GAUGE WHEEL
26C 1 BP3079 SET SCREW, SQ HEAD, 5/8”-11 X 1-3/4”
26D 1 BP3080 NUT, HEX JAM, 5/8”-11, GRADE 2
26E 1 BP3211 NUT, HEX, 5/8”-11, GRADE 2
26F 1 AAM2707 ASSEMBLY, HUB & SPINDLE, 511 HUB, 1-3/4” X 13”
26G 1 AAM2781 WHEEL, 20.5 X 8.0-10, 10 X 6, WHITE
26H 1 BM3547 PIN, 1-1/4” X 5-3/4”
26I 1 BP3051 PIN, 1” X 6”, PLATED
26J 2 BP3249 MACHINERY BUSHING, 1-7/8” OD X 1-1/4” ID, 14 GAUGE
26K 2 AP2711 SNAP RING, 1-1/4” EXTERNAL, HEAVY DUTY
26L 1 BP3350 U-BOLT, 3/4”-10 X 6”W X 7-11/16”L, PLATED
26M 2 BP3035 WASHER, LOCK, 3/4”, PLATED
26N 2 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
26O 1 BP3500 PIN, HAIR CLIP, 3/16”
