11
ASSEMBLY INSTRUCTIONS
3
17
1
2
N
F
N
Pull back on collar at the other end of high pressure
hose (N). Push rmly to connect hose to power washer
unit. Twist collar to secure. Conrm hose is locked into
power washer unit by slightly pulling on hose. The hose
is now securely attached.
Insert extension lance (*I) into nozzle holder (H), and
press spray gun (K) with extension lance (*I) into spray
gun holster (M).
2
1
F
H
M
*I
K
18
Foam Cannon Storage
Store the foam cannon (O) on the back of the power
washer unit (C).
16
O
Attach Foam Cannon (O) into end of lance by
pressing cannon into place. It will make a “click”
sound when rmly in place.
Note: Always lock spray gun when changing the foam
cannon to ensure it does not eject with force.
• When using the foam cannon, ll it with a properly
formulated detergent or cleaner with water ratio
according to instructions on the container.
*I
O
15
95509_IM_BC 2N1 HSS_ENG-FR-SP（Thankyou letter）.indd 11 2020/5/22 下午4:45
