BLUM AVENTOS HL User Manual

Subject to technical modifications without notice. © 2015
6
WARNING
Remove the cover caps and cover plate.
2
Remove the covers
1
Removing the door
Open the door. Support the door with one
hand and push down on tab to disengage the
CLIP mechanisms on the arm assemblies of
the mounting plates.
Lift the door off the mounting plates.
1
2
Removal
Risk of injury from spring-loaded arm
▀ Do not push arm assembly down or leave in the down position
▀ Remove mechanism before installing or removing cabinet

BLUM AVENTOS HL Specifications

General

Category	Lift system
Cabinet width range	Up to 1800 mm
BLUMOTION	Yes
SERVO-DRIVE	Optional
Application	Lift system for wall cabinets
Cabinet height range	300 mm to 580 mm
Motion technology	BLUMOTION
Material	Steel
Adjustment	3-dimensional adjustment
Opening Angle Stop	Optional
Mounting	Screw-on system
