BLUM SERVO-DRIVE

✓✓
75°
p
p
NBY
13
HF / -HS / -HL / -HK
HF / -HS / -HL HK
EN
Distribution cable installation
Drive unit adjustment
SERVO-DRIVE for AVENTOS
Drive unit assembly
➢ Before SERVO-DRIVE for AVENTOS assembly, the lift mechanisms
must be set so that the front remains open in different positions.
➢ If required, attach the opening angle stop only after drive unit installation
and before the reference run.
NOTE
➢ The telescopic arm and/or lever arm must be in the completely open
position for drive unit installation.
